Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 93

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 93
188. CORLISS VALVE GEAR. In thisdesign, B is the bell crank, which carries thehook H mounted on a short shaft, on theother end of which is the trip lever (not shown),which engages with the knock-off cam C, oper-ated by the governor rod. K is the drop leverwith dashpot connection. The cam lever… … 190. CORLISS VALVE GEAR. Thisdesign consists principally of a curved bellcrank, B, carrying the grab hook D mountedon a short shaft having an arm at the otherend. The trip lever d rides on the knock-offcam A, the position of which is controlled bythe governor, as usual. When the bell crankreaches…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
