Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 101

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 101
DASHPOT GOVERNOR. The eccentric is mounted on aplate G, pivoted at P, and is connected to E B, No. 1, and E B, No. 2, by connecting rods in such a manner thatthe action of centrifugal force in throwingthe weights B B outward cause the centerof the eccentric to swing toward the centerof the shaft.… … STEAM POWER APPLIANCES. 9?

Mechanical movements
