Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 110

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 110
STEAM POWER APPLIANCES. I05 … 250. ROTARY ENGINE. Harrington type. The disks have abearing surface of several inches on each other, preventing the passage of steam between them. An end elevation partlyin section, showing the piston A, and the abut-ment disk B, in position at the instant oftaking steam through a port from the…

Mechanical movements
