Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 111

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 111
ieldingblock in a recess on its periphery,the eccentric also acting alternatelyto press back abutment blocksadapted to slide on antifrictionball bearings in recesses in thearms of the casing. The steamsupply pipe connects with a pas-sage communicating with a circularchamber in which is a rotary… … STEAM POWER APPLIANCES. 107 right hand pipe. The valve chamber also connects with a steam dis-charge pipe, the valve being turned by means of a handle or wheel todirect the steam into one or the other of the branch tubes, when theopposite tube will form the outlet pipe for reversing the engine.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
