463. LINK OR CONNECTINGROD, with adjustable brasses. Keysinside and outside of pins. 463a. STAKE PULLER. — Aneasy way to pull stakes and posts. Aclevis to pinch the stake or post againstthe end of the lever with the leverpivoted to the foot post. 463^. STALK PUL-LER. — The conicalspiked drums catch… … 463^. V A L V EGEAR FOR EX-PLOSIVE MO-TORS.—H, air inlet;F, air valve; G, gasor gasoline valve; /,air valve lever; B, gasvalve lever operatedfrom the cam at C;O, exhaust; E, ex-haust valve; e, ex-haust valve lever, op-erated by cams at c.
