Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 119

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 119
H4 EXPLOSIVE MOTOR POWER AND APPLIANCES. … 267. COMBINED GASOLINEAND STEAM MOTOR. In this de-sign the piston of the explosive motor ismade the crosshead for the connectingrod. A duplex steam engine with aduplex explosive motor as an auxiliarypower in which the exhaust of the steamengine may also be turned into the ex-plosive motor cylinder…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
