Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 121

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 121
red charge of oil. The hit or miss is regulated bythe lifting of the pick blade on the incline of the wedge beneath thecollar of the pick blade, which is made adjustable by the nut and screwon the pick blade. The wings of the conical vaporizer are shown inthe section. Il6 EXPLOSIVE MOTOR POWER AND… … D !! 12

Mechanical movements
