Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 131

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 131
frame on piles, or on floats in a stream, shows increased power by thelarge number of submerged buckets. 295. FLOATING MOTOR FOR RIVERS. A wheel of thewindmill type is hung within a bell-mouthed case, which may be … ^^5^^?^?^ ^ T^-^^isgFssr?^ lowered or drawn up to clear the varying depth of a stream and toutilize the full value of the increased velocity at mid depth. Poweris transmitted to the shore, or may be used on the floats for pumpingwater for irrigation. 296. Cross section, showing wheel and frame.…

Mechanical movements
