Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 142

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 142
fastenedto a reel on board the flat boat, which in turn was connected by gearsto a shaft that carried paddle-wheels on each side of the boat, heaccomplished his task. After the boat was loaded, the paddle-wheelswere connected to the reel, which was slowly revolved by the actionof the current and… … 3, JWheel DriveShaft Receiver Receiver 332B. HYDRAULIC POWER TRANSMISSION. The prin-ciple on which the transmission operates may be briefly explained asfollows: It consists in regulating the flow of liquid from the pumpto the receiving motors in such a manner that the liquid is caused to act…

Mechanical movements
