Automobile driving self-taught; an exhaustive treatise on the operation, management and care of motor cars (1912)
Russell, Thomas Herbert, 1862-1947 · Chicago, Charles C. Thompson co. · leaf 172
Splitdorftransformer type magneto is shown by Fig. 4, in which A, B,C, and D are terminals for the spark plug connections. Thecoil and switch shown at the left in circuit diagram are con-nected with an auxiliary dry battery which is generally usedin starting the motor. A total advance angle of 17… … FIO. P5.<-.FR0NT VIEW OP THE EISEMANN MAGNETO. a high tension current in the secondary winding of an induc-tion coil. This high tension current is then brought backfrom the coil to be distributed by a distributer forming partof the magneto mechanism. There are several types of thismagneto used;…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
