Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 22

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 22
y a rod connectedat its other end to the bar pivoted tothe lateral frame on the pole. Thesingletrees on the opposite side of thepole are pivoted to the end of abar extending across the pole andpivoted to the crossbar. By thisconstruction the draught of the horsessecured to all the singletrees will… … i8 MECHANICAL POWER, LEVER.

Mechanical movements
