Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 222

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 222
Two-cylinder engine directly connected to a two-speed change-gearshaft and to a compensating shaft gear, which in turn is geared insideof the rear wheels. … 559. Plan of steam freight wagon running gear, with change gearconnections. 218 ROAD AND VEHICLE DEVICES, ETC. 560. STEAM DRAY. Type of theLeyland dray, much in use in England.Uses a kerosene burner under a verticaltube boiler, with double-reducing chain-gear system. Compensating gear on…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
