Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 250

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 250
SECTION XV. MOTION AND CONTROLLINGDEVICES, ETC. 244 Section XV. MOTION AND CONTROLLING DEVICES, ETC. … 631. PARALLEL MOTION. Peau-celliers seven links. The pivots on thesquare plates are fixed points. The jointat A makes a straight line. All the shortlinks are equal to the length of the fixedpivots. The other links are three timesthe length of the short links. 632. PARALLEL MOTION. The three pivots…

Mechanical movements
