Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 317

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 317
and oily matters, which are utilized fortheir oil and the refuse for manure. The kernelspass through the screen, while the coarser hullsand fibers are carried along and discharged fromthe lip of the screen. The hulled seed is then re-ceived into the box-screen I, which,being shaken by suitable… … 811. COTTON BAT COMPRESSOR AND CONDENSER. a, lint flue; b, condenser drum; d, d, bat-former aprons; e, compression roll; /,/, baling rolls; g, core;h, baling belt; i, belt idler;j, hydraulic cylinder; k, pres-sure column; I, press pulley;m, bat-former pulley; n, pis-ton rod; p, r, tension rolls;s,…

Mechanical movements
