Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 322

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 322
3i3 TEXTILE AND MANUFACTURING DEVICES, ETC. 824. EVOLUTION OF THE LAG SCREW and the machinefor making them, showing the general construction of the cutter and the principle upon which it operates, b being alag screw which is being cut and c the cutter, eachrevolving in the direction indicated by…

Mechanical movements
