Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 376

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 376
PERPETUAL MOTION. 371 r^s g … 928. PERPETUAL MOTION. Geared motive power, a is theaxis or shaft on which the wheels are all mounted ; each wheel consists of two parallel rims, b, b, eachof which is connected by radialarms, c, to a boss, d, keyed onthe axis, a; the working partsof each wheel are mounted be-t w e e n the rims and…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
