Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 58

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 58
g handis run down to zero. When the spring is first put in, it is wound upthree turns so as to keep proper tension on the movement. Thearbors of the wheels run in plates, one of which may be solid with thebeam in which the spindle runs. SECTION IV. GENERATION OF POWER,STEAM. 52 Section… … A liberal steam space and dry pipe prevents siphoning.74. Cross section of boiler.Continental type.

Mechanical movements
