Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 60

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 60
Arranged for utilizing the heatfrom a puddling furnace.A most efficient econ-omizer of heat from anykind of furnace fromwhich there is sufficientwaste heat for generatingsteam. A diaphragmguides the heat to bestadvantage through thetwo sets of upright tubes. GENERATION OF TOWER, STEAM. 55 … 80. VERTICAL WATER TUBEBOILER. Wood type. A furnacechamber at one side j an upper andlower tube drum with the tubes bankedin two sections, and a fire-tile partitionextended nearly to the top of the tubes.The only provision for circulation is bythe upward current in the fire side induc-ing a…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
