Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 83

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 83
nomy is wanted, theintercepting valve is turned to the position shown in the right section,closing the free exhaust from the high-pressure cylinder and the livepressure connection to the low-pressure steam chest and compellingthe exhaust of the high-pressure cylinder to enter the receiver and…
