Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 94

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 94
which shortens the stroke of thevalves and consequently changes the point of cut-off in the cylinder. STEAM POWER APPLIANCES. 89 186. CORLISS VALVE GEAR and release mechanism, stand-ard type. A, valve stem. A bell crank operated by a connecting rod fromthe wrist plate, lifts the grab hook, E, and… … WIST PLATE 187. CORLISS VALVE GEAR and release mechanism. Thegrab hook consists of a block, C, sliding in a grooved slot in the bell-crank lever B B, and normally forced out-ward by a spring. The block C carries apin, E, on the rear side, which is held incontact with a cam ring, F, having twov\N,…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
