Mechanical drawing problems for high schools, normal schools and vocational schools (1918)
Berg, Edward. [from old catalog], Kronquist, Emil F. (Emil Fritjoff), b. 1882 · Peoria, Ill. : The Manual arts press · leaf 68
64 MECHANICAL DRAWING PROBLEMS Specification—Plate 14 A. Make a complete working drawing of the Pin Bearing. Scale I2=i. Title:— PIN BEARING SCALE DATE . NAME 1. Why are the front and side views preferred to the front and top views in the drawing of the PinBearine? PLATE 14A … 66 MECHANICAL DRAWING PROBLEMS Specification—Plate 15. Make an assembly drawing of the Book-rack showing two views. The constructionshould be shown and all parts dimensioned. In the picture drawing one end is removed toshow the construction. Scale 6=i. Title:— BOOK-RACK SCALE SATE NAME A bill of…
