Mechanical drawing for secondary schools (1916)

Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 163

An illustration from Mechanical drawing for secondary schools, 1916, leaf 163
Fig. 163. Keyed Mortise and Tenon 2. To make a pencil mechanical drawing from the ortho-graphic sketch. 158 MECHANICAL DRAWING … Tig. 164. Toot Stool

Mechanical drawing
