Mechanical drawing for secondary schools (1916)

Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 46

An illustration from Mechanical drawing for secondary schools, 1916, leaf 46 — the enclos- PERSPECTIVE SKETCHING 41 ing solid must be estimated. Half the sum of these two distancesshould fall above and half below the center of the sheet. DATA FOE DRAWING PLATE 3 Given: The dimensioned perspective sketch of a cord-windwith the upper surface 3 below the level of the eye. Fig.… … Fig. 32. Constructive Stage Complete 2. To draw the cord-wdnd full size with the upper surface 5below the level of the eye, and turned so that the longer edgesvanish toward the left instead of toward the right. 3. To draw any similar object assigned by the instructor.
