Mechanical drawing; a treatise on the drawing of mechanical and machine details (1920)
Jones, Franklin Day, 1879-1967 · New York, The Industrial press; [etc., etc.] · leaf 115
Machinery Fig. 4. (A and B) Two Methods of sectioning Parts bolted together. (C) Sectionof a Casting having Three Lugs followed. The method of representing the gear teeth in sec-tional views is generally as shown. (The common methods ofdrawing gears will be dealt with in Chapter IX.) Sectional and…
Mechanical drawing
