Mechanical drawing; a treatise on the drawing of mechanical and machine details (1920)
Jones, Franklin Day, 1879-1967 · New York, The Industrial press; [etc., etc.] · leaf 30
rawings or as a means of understanding them, but by study-ing first very simple drawings and then those that are morecomplex, the various methods of representing practically anymechanical device will be apparent The principal point tobear in mind when making mechanical drawings is that theyare to… … Fig. 4. Simple Example of Projection Simple Examples of Orthographic Projection. — Since thebest way for the student of drafting practice to become fa-miliar with mechanical drawing methods is by studying draw-ings of various kinds, examples representing distinct typeswill be considered, beginning…
