Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 104
as only 1-24-inch, which wouldbe too small to show well. It will usuallybe found almost impossible to adhere tothe scale on the piping for the reason justgiven. We would advise the reader as ex-cellent practice work, to work out theseveral floor plans on some scale largerthan that which we have…
Plumbing · Mechanical drawing
