Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 70
e work, viewing each sectionfrom the most advantageous position. shown in Fig. 75. It will be observedthat in order to obtain this elevation thework must be viewed looking in the direc-tion in which the arrow B points. Inthis particular layout of the work the en-tire elevation is clearly shown from… … to find a layout that can be handled inthis way, of work of such extent, butwhenever possible, this course should befollowed. A glance at Fig. 75 will showthat while the bath room and kitchen fix- tures are on a line with each other, orvery nearly so, the pantry sink and re-frigerator are off at…
Plumbing · Mechanical drawing
