Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 137
J^lfllN C0RN/C£ PLATE 123—DETAIL OF MAIN CORNICE ON BRICK HOUSE Substantial cornice construction for a brickhouse. The cornice is of the wide extending boxtype, the roof being given a perceptible flare atthe eaves by means of two by four pieces nailed onto the rafter ends. Note method of… … PLATE 124^DETAILS OP PORCH CONSTRUCTION Working drawings showing the design andconstruction of a porch with classic columns rest-ing on a brick and stone base. Note novel methodof constructing porch cornice to make the eaves trough invisible. Special attention is called to thefact that all the…
Building · Architecture
