Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 76
Elevation of Plumbing: in Kitchen. MECHANICAL DRAWING FOR PLUMBERS 73 … Fig:. 83.—Elevation of Plumbing- in Toilet Room,horizontal line in the cellar we show en-larged in size in Fig. 85 of our next arti- cle. In order to economize space we showthe stack cut off with broken lines on thesecond floor and in the attic, and bringthe roof and attic floor and attic floorand…
Plumbing · Mechanical drawing
