Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 80
Fig. 84 can be shown twice as large asgiven, but the remaining sketches can bedrawn up in the same size as we presentthem. We might add here, that in working uphis drawings, the student would do wellto practice lettering, following the styleof lettering used on our illustrations, forit is a fact…
Plumbing · Mechanical drawing
