Mechanical drawing. Prepared for the use of the students of the Massachusetts Institute of Technology, Boston, Mass (1887)

Faunce, Linus · Boston, W.J. Schofield, Printer · leaf 57

An illustration from Mechanical drawing. Prepared for the use of the students of the Massachusetts Institute of Technology, Boston, Mass, 1887, leaf 57 — Cyma Recta … Cyma Reversa The Roman moldings are given above, the method of con-struction being evident. All the arcs are arcs of circles, andthe angles are 45°, except in the flatter form of the cyma recta,where the line of centres is at 30°. CHAPTER III. INKING. 14. It is supposed that the student has now…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
