Pour Supportsat 90°apart Tap for / c/ra/nSteam Jacket Fig. 324. Probs. 174 and 175. Completely dimension the drawing. The jacket is supported upon four supports, shownpictorially. The flange of the kettle rests upon the flange of the jacket and is bolted toit. Use large sheet. (Fig. 236.) ,ii… … Fig. 325. Probs. 176, 177 and 178. Hand Pump. PROB. 176, Fig. 325.—Make a detail working drawing of the PUMP BODY. PROB. 177, Fig. 325.—Make a working drawing showing each detail separatelyfor the iVs plunger pump, for all parts except the pump body. Use large sheet. PROB. 178, Fig. 325.—Make an…
