lines (a,b, c) are used to get the radius wherefrom to markthe arcs where the points In the ellipse shall fall; thus,radius a gives points i, 2, 3 and 4; radius b givespoints 5, 6, 7 and 8, and radius c gives 9, 10, 11 andI 2, the extreme diameter being obtained from lines S,Z, and H, H. CHAPTER… … tooth; E is the height or depth, and F the breadth.P P is the pitch circle, and the space between the twoteeth, as H, is termed a space. It is obvious that the points of the teeth and the13 (193) 194 MECHANICAL DRAWING SELF-TAUGHT. bottoms of the spaces, as well as the pitch circle, areconcentric…
