Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments. Elementary instruction in practical mechanical drawing. Together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers (1889)

Rose, Joshua · Philaelphia, H.C. Baird & co.; [etc., etc.] · leaf 394

An illustration from Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments. Elementary instruction in practical mechanical drawing. Together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers, 1889, leaf 394
Fig. 330_IOO h. P. Horizontal Steam-Engine— Connecting Rod. (Page 294.) INDEX. Ames lathe feed motion, drawing a part of, 20S.Angle of three lines, one to the other,to find, 55, 56.of two lines, one to the other, tofind, 54, 55, 56.Angles, acute arid obtuse, 57.Arc of a circle, an, 50.Arcs,…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
