1rr=i_ -frr TT PLATE 46 70 MECHANICAL DRAWING PROBLEMS CONE AND CYLINDER The intersection of the cone and cylinder is found by dividingthe base of the cone into any number of equal parts. From thesedivisions draw the front and the side views of elements of thecone. Project from the point where the…
