Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 176
es upon the bearings, particularly those com-ponents of the effort of a single cylinder which the bearingsmust endure when the connecting-rod is working at anglesunfavorable to rotative effect. This arrangement is especiallyfavorable for vessels intended for shallow water, as it diminishesthe… … Fig. 94. 124 MECHANICAL ENGINEERING OF POWER PLANTS. The low-pressure piston is always moving in the directionopposite to that of the high, and consequently the exhaustfrom the completed stroke of the high-pressure piston crossesstraight over to the same end of the low-pressure to drive itin the…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
