Locomobile Carriage and Its Engine.—One of the most efficient among the American double-acting simple enginesis that operating the Locomobile steam carriage, which hastwo cylinders of 2\ inches diameter by 4-inch stroke, and a total 012 SELF-PROPELLED VEHICLES. output of 4 to 5 horse-power, at… … FlG. 450.—The Locomobile1 Steam Carriage Engine. accompanying drawing, carries the sprocket at the centre, theeccentric drums on either side, and runs in enclosed ball races,with the cranks at either extremity. The cranks are fixed at90 degrees. As seen from the accompanying figure of the en-…
