Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 287
tre of the link. Thevalve-rod and stem are attachedto the eccentric-rod /at the pointwhich will give the desired throwto the valve. If the centre ofthe link J be thrown over to theright, the engine will reverse,and at intermediate positions thethrow of the valve is diminishedand cut-off takes…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
