Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 90

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 90
273. PEAUCELLIERS PARALLELMOTION.—A, B and B, C are of equal distances^when the connecting rod will move in a straightline. When B is connected with the outer jointof the link quadrangle the inner joint C will_ have a straight-line motion. D© Cfi § ^F 274. PARALLEL MOTION,side-lever marine… … 275. PARALLEL MOTION, for a side lever marine engine. a and I? are of equal length.^ and d are of equal length. Radius of rocker-shaft crank F = -*— e

Mechanical movements
