Mechanical equipment of buildings; a reference book for engineers and architects (1916)

Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 530

An illustration from Mechanical equipment of buildings; a reference book for engineers and architects, 1916, leaf 530 — Fig. 33. Monash Air Valve. Fig. 34. Breckenridge Air Valve for Steam Mains. until steam again enters. The plug is mounted in an adjustable brass head which may bereadily adjusted with a screw-driver after removing the cap. The hollow plug valve (Fig. 33)has an adjustable seat (4), which is capable…

Building · Heating · Ventilation
