ng, andhence is a measure of the torque. In usual operation small variations of the torque, due tobelt flapping, etc., make the clicking position somewhat variable.It is therefore convenient to read the maximum and minimumangles at which no click is heard and to take the average of theseas the… … Fig. 30.—Flather Dynamometer. The fluid pressure thus produced is transmitted through tubes,t, and a longitudinal hole through the center of the driver shaft.Connecting with this hole at the end of the shaft is an indicatorby which a graphic record of the pressure is made. Since thispressure is…
