atit will open after the exhaust valve has closed; otherwise therewould be a tendency for theexhaust gases to enter the in-take. The closing of the inletvalve takes place after crankend dead center so as to pro-vide a good opening for thecharge. The correspondingcrank angle may be as muchas 20° to… … Suction Fig. 101.—Otto Cycle.
