1 is compressing, cyl-inder No. 2 is exhausting. During the time that the chargein cylinder No. 1 is exploded, cylinder No. 2 is being filledwith fresh^gas. While the exhaust gases are being dis-charged from cylinder No. 1, cylinder No. 2 is compressingthe gas previously taken. The same condition… … /V-U\ M H ~ Two Cylinder VerticalCrankpins on Same Plane
