Mechanical laboratory methods; a testing of instruments and machines in the mechanical engineering laboratory and in practice (1918)
Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 76
Pressure Fig. 35. Fig 36. Correction of Indicator Diagrams. It is then necessary to reconstruct the diagram to get correctresults. A method of doing this is as follows. Calibrationdata are obtained as previously described, and plotted as shownby Fig. 35. The range of pressure P for the calibration…
Mechanical engineering laboratories
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
