nt of the spring? Arts., 0.5 and 2.0 lbs. per in. 12. The Testing of Link Type Reducing Motions Principles. The pantagraph in various forms has been muchused to reduce engine cross-head motion for the purpose of drivingindicators. Fig. 41 shows a number of them, diagrammatically.In these and in the… … Fig. 41.—Pantagraph Reducing Motions. There are two conditions necessary to the proportionaUty ofmotion of the points R and C. First, they must lie on a straightline passing through F, and second, the links that are parallelin one position must remain so in all positions. Fig. 41 A and B are…
