Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 114
ve for both cylinderswith direct steam passagesthrough the valve chamber.High pressure steam entersat the central port A. Steaminlet and exhaust indicated bythe arrows. Section V. STEAM APPLIANCES. Injectors, Steam Pumps, Condensers, Separators, Traps, and Valves. 372. PEERLESS IN-JECTOR.—An…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
