Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 116
BROWNLEY INJECTOR.— The steam flows to the double-jet nozzles without any regulat-ing device other than the over-flow cock, which by this pecu-liar construction relieves bothlift and force tubes. LEADER INJECTOR.—A double-tube injector. Aseparate valve gives steamto the lifting nozzle A, withthe… … To BOILER OVERFLOW 1 387. EXCELSIOR INJECTOR.—A separate valve gives steamto the lifting nozzle A, theoverflow cock D C beingopen. The first movementof the handle opens the coni-cal valve <^ y a further move-ment closes the overflow cockD C to both the lifting andforce overflow S.
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
