PENDULUM WATER LIFT.—A double seriesof scoops with flap valves and connecting pipes.The swinging of the pendulum frame alternatelyimmerses the lower scoops, and at the next strokeraises the water by its transfer to the oppositescoop, when the next oscillation transfers to thenext opposite scoop,… … 523. RECIPROCATING MOTION by the auto-matic action of a fall of water. A bucket with a valvein the bottom, which lifts and discharges the water bythe contact of the valve spindle with a stop at thebottom of the bucket run; the weight lifting thebucket again to the spout. Very old.
