Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 260
t illustrating thechanged conditions of gear motion. Gears a andh are fixed to the crank shaft. Gears g and Jare fixed to a hollow shaft turning on the shaftn 791. Gears e, b are fixed on a hollow shaft andturn on shaft 71 771. The arm >^ / is fast on andsupported by shaft n m. Gears e, d are…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
