loii. INTERMITTENT MOTION of a ratchetby the oscillation of a knuckled joint tappet arm.The spring keeps the tappet extended on the for-ward stroke, and allows it to run over the tooth ofthe ratchet on its return. … 1012. INTERMITTENT CIRCULAR MO- O A 7 TION of a ratchet wheel with a check pawl by/ the continuous circular motion of a pawl wheel. proportions.
